Detailed description
| Roller turning Lathe | ||
| Item | Unit | CAB8450 |
| Max. machining workpiece diameter | mm | 500 |
| Max. length of workpiece | mm | 2500 |
| Height of center | mm | 300 |
| Max. workpiece weight | t | 3.5 |
| Max. cutting force | KN | 32 |
| Faceplate maximum torque | KN | 8 |
| Number of spindle speeds | / | 12 |
| Range of spindle speeds | r/min | 2-90 |
| Travel of tailstock sleeve | mm | 200 |
| Main motor power | KW | 15 |
| Machine overall demension | mm | 5.2×1.4×1.4 |
| Machine weight | kg | 7500 |
